Machinability
Makino with 4th axis Machine
Control System
FANUC Professional 5
Axis Travel
X – 605 mm, Y – 450 mm, Z – 460 mm
Spindle Speed
Maximum 12000 RPM
MS MCV 400 with 4th axis Machine
Control System
FANUC Oi- Mate MD
Axis Travel
X-520 mm, Y-450 mm, Z - 500 mm
Spindle Speed
Maximum- 6000 RPM
ACE Designers Turning Centers
Control System
FANUC Oi Mate-TD
Axis Travel
X – 250 mm, Z – 300 mm
Spindle Speed
Maximum 6000 RPM
BFW Machining Center with 3 axis
Control System
FANUC Oi Mate-MD
Axis Travel
X – 400 mm, Y - 410 mm, Z – 430 mm
Spindle Speed
Maximum 6000 RPM
AMS MCV 400 with Pallet Changer
Control System
FANUC Oi Mate -MD
Axis Travel
X – 650 mm, Y – 450 mm, Z – 500 mm
Spindle Speed
Maximum 6000 RPM
HAAS VF Machining Center with 3 axis
Control System
HAAS
Axis Travel
X – 600 mm, Y – 300 mm, Z – 400 mm
Spindle Speed
Maximum 8100 RPM
HMT GCL- 60 Center less Grinding Machine
Spindle Speed
Maximum 1800 RPM
Machine Accuracy
0.002 mm
Single Spindle Automatic Lathe - A42
- Multiple tool simultaneous working.
- Attachment for drilling, turret, grooving, long turning etc.
Quality Testing Infrastructure
Coordinate Measuring Machine (CMM)
Make
Carl Zeiss
Model
Contura G2
Axis Travels
X – 700 mm, Y – 1000 mm, Z – 500 mm
Software
CALYPSO 6.4
Accuracy
0.0001 mm
Surface Roughness Tester
Make
Carl Zeiss
Model
Surfcom Touch 50
Maximum Measuring Length
50 M
Roundness Tester NEX 200 SD 11
Make
Carl Zeiss
Model
Rondcom NEX
Accuracy
0.0001 mm
Profile Projector
Make
Mitutoyo
Axis Travel (manual)
X-200 mm, Y-100 mm, Z-152 mm
Maximum Measuring Length
50 M
2D Height Master
Make
Tesa
Model
Tesa 700
Axis Travel
Z – 700 mm
Accuracy
0.0001 mm
Contour Tracer
Make
Zeiss
Model
Contourecord 1600G-12-N
Axis Travel
X – 100 mm, Z – 50 mm
Accuracy
0.0001 mm
Software
ACCtee
